Technology

Electrochemical

Measurement Range

1-25% vol O2

Maximum Overload

30% vol O2

Output Signal

0.10 ± 0.02 mA in Air

Response Time (T90)

<15s

Zero Current (Offset)

<0.6% vol O2

Linearity

Can be considered linear inmany cases.See Operating Principles(OP-02) for further details.

ELECTRICAL

Recommended Load Resistor

100 Ω

MECHANICAL

Casing Material

ABS

Weight

<16 g

Orientation Sensitivity

 <0.2% vol. 0, equivalent

ENVIRONMENTAL

Operating Temperature Range

 -20℃to +50℃(up to 3 montcontinuous across RH range)

Recommended Storage Temp

0℃ to 20℃<

Thermal Transient(Temp. plunge +22℃ to -20℃)

<23.5% vol. O2

Operating Pressure Range

Atmospheric± 20%

Pressure Transient(60 cm H2O step change)

<200% signal change

Relative Humidity Range

(at 0℃ to 20℃)

Continuous

5 to 95%RH non-condensing

Short Term

0 to 99%RH non-condensing

LIFETIME

Long Term Output Drift

 <2% signa lmonth

Typically<5% over operating life

Expected Operating Life

Minimum 24 months in air

Storage Life

6 months in original packaging

Warranty Period

24 months from date of despatch
