Operating Principle

2-electrode electrochemical

Measurement Range

0-2 ppm O2

Maximum Overload

1000 ppm o2

Filter

None

Output Signal

50 - 80 mV in air with a 10Ω

load resistor

Response Time (T90)

<20 seconds at 20℃

Purge Time:(Ambient air to<10 ppm)

<6 hours

Linearity

Linear

ELECTRICAL

Recommended Load Resistor

10Ω

Weight

32 g

Housing Material

Body

Nickel plated steel

Current Collectors

Nickel

Orientation Sensitivity

None

ENVIRONMENTAL

Operating Temperature Range

 -20℃ to +50℃

Temperature Coefficient

0.2% signal/℃

Recommended Storage Temp

0℃to 20℃

Operating Pressure Range

Atmospheric ±10%

Operating Humidity Range

0 -99%6 RH non-condensing

LIFETIME

Long Term Output Drift

<5% signal loss/year

Expected Operating Life

See below

Storage Life

6 months in CTL container

Standard Warranty

12 months from date of despatch
